Gates/flaps/divertors/ditributors

"Easy, Entry & Exit (EEE)"

  • Frame made out of formed bend section.
  • Powder coated surface finish for long life and better appearance.
  • Use of Magnetic Pneumatic Cylinder to trace the real feedback of CLOSE/OPEN position.
  • Use of silencers in exhaust ports of solenoid valve for smooth and noise free operation.
  • Use of UHMW/ Rubber lining at joints for a leak proof enclosure.
  • Hindrance free inlet and out let for free flow of material in minimum time.


Pneumatic two/ three way flap - 'V' type & 'Y' type


V & Y Type Model V Type Model
RK2WF 20 x 20 RK3WF 20 x 20
RK2WF 25 x 25 RK3WF 25 x 25
RK2WF 30 x 30 RK3WF 30 x 30

Pneumatic dump flap


Model No. RK-PDF Opening (mm x mm)
50 x 50/50 500 x 500
60 x 60/63 600 x 600
24 x 100/80 235 x 1000
24 x 150/80 235 x 1500
30 x 100/80 295 x 1000
30 x 150/80 295 x 1500



Pneumatic Slide Gate


Model No. RK-PSG Stroke (mm)
20 x 20 195
30 x 30 295
40 x 40 395
45 x 45 440
45 x 50 440
50 x 50 490
295 x 900 SP 290
400 x 120 SP 395
