• Achieves higher fill level in compact structure.
  • Ultra high speed mixing at 90% fill level.
  • Direct steam absorption through multi orifice steam manifold with individual control.
  • Large volume conditioner with big diameter shaft.
  • Offers higher mixing intensity.

Model no. Capacity (tph) Power (hp) Volume (litres) Rotor (rpm)
RK1RC 32 X 240 6 - 8 3 - 5 170 210 - 280
RK1RC 40 X 240 8 - 12 5 - 7.5 250 210 - 280
RK1RC 50 X 240 12 - 15 5 - 7.5 390 200 - 300
RK1RC 50 X 300 15 - 20 7.5 - 10 510 200 - 300
RK1RC HV 50 x 280 12 - 16 15 - 20 425 180 - 300
RK1RC HV 60 x 300 15 - 20 20 - 25 730 150 -270
RK1RC HV 65 x 300 20 - 26 25 - 30 1000 150 - 270
